ZK-JGZX-2515 Glass processing center
Machine performance overview:
ZK-JGZX-2515 CNC Glass Processing Center is an economical processing machine.This machine tool can rough and finish machining of glass,rock slabs,ceramics and other materials,it can also perform efficient, large-volume, and high-precision processing of complex special-shaped workpieces.
The whole machine:Mechatronics design, advanced structure, reasonable layout, beautiful appearance, using an integral bed with excellent rigidity and stability;the whole machine has an automatic lubrication system.
Spindle:The spindle bearing adopts C-level bearing; the spindle rotation runout is small and the accuracy is stable.
Move:The X/Y/Z axis of this machine adopts three-axis full screw drive of a well-known domestic brand,which has excellent motion accuracy and dynamic characteristics.
System:It adopts a special system for drilling, milling and edge grinding, all driven by servo motors, with reliable performance and visibility.
Graphical interface, easy to operate.
Machine tool processing range:
1.This machine can perform rough machining and finishing of hard and brittle materials, and is especially suitable for Automobile, machinery and other industries,efficient and large-scale processing of glass, rock slabs and ceramics,high-precision processing.
2. This machine can also process other materials by replacing the cutting tools.
3. This machine is also suitable for small and medium-sized batches of plate-shaped and special-shaped materials.
The processing scope of the machine should be determined based on the machine specifications and its technical parameters. Processing beyond machine specifications and permitted parameters is prohibited.
For the processing range of the machine,please refer to the technical parameters of the machine tool.
| Model | ZK-JGZX-2515 |
| Spindle travel( Axis) | X Axis | 2500mm |
| Y Axis | 1500mm |
| Z Axis | 350mm |
| From Bottom of Z axis to working table | 350mm |
| Working Table(25mm 6061 aluminum ) | Working table area | 2500MM*1500MM |
| Max Loading | 300KG |
| Milling work table | 2500MM*1400MM |
| Machine thick-walled square | Welding,heat treatment,vibrating ageing treatment |
|
| stainless steel sheet | 1.2MM |
| Spindles(For Edging Only) | Wheel Diameter | 50-160MM |
| Rotate Speed | 9000-12000 rpm |
| rotating mode | Three-axis full screw drive |
| LUBRICATION | No. 68 lubricating oil |
| Cooling System | CW3000 refrigerator |
| Spindle motor |
|
| 3 Axis motor horsepower | Taiwan Delta 1.3kw |
| Feed Speed | X,Y axis Speed | 20000mm/min |
| Z axis speed | 5000mm/min |
| Max cut feed speeds | 6000-12000mm/min |
| Precision | Positioning Precision | ±0.05 |
| Repeatability | ±0.03 |
| finished product precision | ±0.2MM |
| Processing Size | Max size:2400*1400mm; | Min size :150*150mm |
| Thickness | 2-19MM |
| Weight and Size | Machine Weight | 5200kg |
| Power Consumption | 15KW |
| Floor Space(length*wide*height) | 4800*2200*1800MM |
| Main Accessories | Spindles | Huadiao-11KW |
| Servo Motor | Taiwan Delta -1.5KW |
| Converter7.5KW | Taiwan Delta -11KW |
| lead screw/ lead rail | Taiwan original TPI |
| CNC System | Special system for drilling, milling, and edge grinding |
| Lubrication system | High-end automatic oil injection pump for machine tools |
| Vacuum pump | 7.5kw water vacuum pump |
| Relay | Schneider, France |
| Switch and indicator light | Schneider, France |
| Contactor | Schneider, France |
| switching power supply | Schneider, France |
| Air leakage,protection switch | Schneider, France |
| Sensors (proximity switch) | Omron |
| Control Transformer |
|
| Knife vault | Six Knives |
| Attachment | Sucker 16 setsPosition 6 sets | silicone ring,nylon column |
| Manual,frequency converter, Servo specification | one set |
